PDI

公司从９５年开始致力于飞利浦半导体在中国市场的产品推广和销售工作，重点推广PHILIPS射频器件和通用分离器件的推广和销售，主要产品有：
PHILIPS RF 器件：
PHILIPS CATV 放大模块、光纤接收模块、PHILIPS 宽带三极管、PHILIPS PIN 二极管、PHILIPS MMIC、
PHILIPS 场效应管、PHILIPS 变容二极管

PHILIPS 通用器件（GA PRODUCT）：
整流二极管、肖特基二极管、开关二极管、齐纳二极管、ESD 防护二极管、普通三极管、BISS（低饱和电压Vcesat）三极管、RET（配置电阻的）三极管
PHILIPS 其它器件：
PHILIPS 逻辑电路、通用模拟IC、视频编解码IC、USB、WI-FI、蓝牙IC等。
公司产品广泛应用于广电、通信、消费电子等领域。
商运达实业是美国ASI公司（ASI Advanced Semiconductors,Inc.）在中国大陆的代理商，代理射频和微波功率器件，商运达实业具有多年从事半导体贸易的经验，与众多知名的电子产品供应商结成合作伙伴，公司为客户提供国内外最先进的资讯、配套服务及供应知名品牌的半导体产品。

商运达实业在北京、香港、上海、成都和深圳均设有办事机构，通过多年不懈的努力，公司在业界具有颇高的知名度并赢得了广大客户的信任和大力支持，强大的技术开发和客户服务队伍，已为中国不同行业的客户提供众多的电子产品设计方案。公司奉行“客户至上”的经营原则，以"为客户创造价值"为经营理念，以可靠的品质为保证，以强大的技术支持和良好的售前、售后服务为基础，为广大客户提供全面增值服务，实现共同发展。
　

商运达实业具有多年从事半导体贸易的经验，与众多知名的电子产品供应商结成全作伙伴，公司为客户提供国内外最先进的资讯、配套服务及供应知名品牌的半导体产品，譬如：
ST AGLIENT ROHM MURATA SAMSUNG ALPHA ON VISHAY INFINEON MOTROLA FIRCHILD

总览

．24V 产品型号
正向放大模块	40-550MHZ	推挽	砷化镓
	40-750MHZ	推挽	砷化镓
	40-870MHZ	功率倍增	砷化镓
			砷化镓-高输出特性
		推挽	砷化镓
			硅
	40-1000MHZ	功率倍增	砷化镓
			砷化镓-高输出特性
		推挽	砷化镓

反向放大模块	5-65MHZ	硅	模块封装
	5-65MHZ	硅	SMD封装
	5-100MHZ	硅
	5-200MHZ	硅

光接收模块	5-300MHZ	硅
	40-870MHZ	硅
	40-1000MHZ	砷化镓

．12V 产品型号
正向放大模块	40-870MHZ	推挽	砷化镓
反向放大模块	40-750MHZ	砷化镓	砷化镓

功率倍增模块

产品名称	频率范围	最小增益	最大消耗电流	最大噪声系数
	(MHz)	(dB)	(mA)	(dB)
D8740320GTH GaAs Power Doubler	40-870	30.8 (@50MHz)/32.0 (@870MHz)	440	4.5 (50-870MHz)
D8740270GTH GaAs Power Doubler	40-870	27.0 (@870MHz)	440	5.0 (50-870MHz)
D8740270GT GaAs Power Doubler	40-870	27.0 (@870MHz)	375	5.0 (50-870MHz)
D8740250GTH GaAs Power Doubler	40-870	25.0 (@870MHz)	440	5.5 (50-870MHz)
D8740250GT GaAs Power Doubler	40-870	25.0 (@870MHz)	375	5.5 (50-870MHz)
D8740240GTH GaAs Power Doubler	40-870	24.0 (@870MHz)	440	6.0 (50-870MHz)
D8740240GT GaAs Power Doubler	40-870	24.0 (@870MHz)	375	6.0 (50-870MHz)
D8740220GTH GaAs Power Doubler	40-870	22.0 (@870MHz)	440	6.5 (50-870MHz)
D8740220GT GaAs Power Doubler	40-870	22.0 (@870MHz)	375	6.5 (50-870MHz)
D8740200GTH GaAs Power Doubler	40-870	20.5 (@870MHz)	440	6.5 (50-870MHz)
D8740200GT GaAs Power Doubler	40-870	20.5 (@870MHz)	375	6.5 (50-870MHz)
D8740180GTH GaAs Power Doubler	40-870	18.5 (@870MHz)	440	6.5 (50-870MHz)
D8740180GT GaAs Power Doubler	40-870	18.5 (@870MHz)	375	6.5 (50-870MHz)
D8740150GTH GaAs Power Doubler	40-870	15.5 (@870MHz)	440	7.5 (50-870MHz)
D8740150GT GaAs Power Doubler	40-870	15.5 (@870MHz)	375	7.5 (50-870MHz)
D10040250GTH GaAs Power Doubler	40-1000	23.5 (@50MHz)/24.5 (@1000MHz)	440	5.5 (50-1000MHz)
D10040250GT GaAs Power Doubler	40-1000	23.5 (@50MHz)/24.5 (@1000MHz)	375	5.5 (50-1000MHz)
D10040240GTH GaAs Power Doubler	40-1000	22.5 (@50MHz)/24.0 (@1000MHz)	440	6.0 (50-1000MHz)
D10040240GT GaAs Power Doubler	40-1000	24.0 (@1000MHz)	375	6.0 (50-1000MHz)
D10040220P1 GaAs Power Doubler	40-1000	21.0 (@50MHz)/22.0 (@1000MHz)	450	4.0 (50-1000MHz)
D10040220GTH GaAs Power Doubler	40-1000	21.0 (@50MHz)/22.5 (@1000MHz)	440	6.5 (50-1000MHz)
D10040220GT GaAs Power Doubler	40-1000	22.5 (@1000MHz)	375	6.5 (50-1000MHz)
D10040200GTH GaAs Power Doubler	40-1000	19.5 (@50MHz)/20.0 (@1000MHz)	440	6.5 (50-1000MHz)
D10040200GT GaAs Power Doubler	40-1000	19.5 (@50MHz)/20.0 (@1000MHz)	375	6.5 (50-1000MHz)

推挽放大模块

产品名称	频率范围	最小增益	最大消耗电流	最大噪声系数
	(MHz)	(dB)	(mA)	(dB)
S8740340PT1 GaAs Push Pull	40-870	34.5 (@870MHz)	300	4.0 (50-870MHz)
S8740340PT GaAs Push Pull	40-870	34.5 (@870MHz)	300	4.0 (50-870MHz)
S8740340C GaAs Push Pull	40-870	34.5 (@870MHz)	280	4.0 (50-870MHz)
S8740280GT GaAs Push Pull	40-870	27.2 (@45MHz)/28.0 (@870MHz)	260	5.0 (50-870MHz)
S8740260GT GaAs Push Pull	40-870	25.2 (@50MHz)/26.0 (@870MHz)	240	5.5 (50-100MHz)
S8740240P12 GaAs Push Pull	40-870	22.5 (@50MHz)/23.5 (@870MHz)	450	3.5 (@870MHz)
S8740240P GaAs Push Pull	40-870	22.5 (@50MHz)/23.5 (@870MHz)	255	3.5 (50-870MHz)
S8740240GT GaAs Push Pull	40-870	23.2 (@50MHz)/24.2 (@870MHz)	240	6.5 (50-870MHz)
S8740230 Si Push Pull	40-870	21.5 (@50MHz)/22.5 (@870MHz)	235	4.0 (@50MHz)
S8740220P GaAs Push Pull	40-870	21.0 (@50MHz)/22.0 (@870MHz)	255	3.5 (50-870MHz)
S8740220GT GaAs Push Pull	40-870	21.7 (@50MHz)/22.7 (@870MHz)	240	6.2 (50-870MHz)
S8740220 Si Push Pull	40-870	21.0 (@50MHz)/21.5 (@870MHz)	235	4.5 (@50MHz)
S8740200P GaAs Push Pull	40-870	20.0 (@870MHz)	260	4.5 (50-870MHz)
S8740190 Si Push Pull	40-870	18.0 (@50MHz)/18.5 (@870MHz)	240	5.0 (@50MHz)
S8740180GT GaAs Push Pull	40-870	17.7 (@50MHz)/18.7 (@870MHz)	240	7.5 (50-870MHz)
S7540340C GaAs Push Pull	40-750	34.0 (@750MHz)	280	4.5 (50-750MHz)
S5540340C GaAs Push Pull	40-550	34.0 (@550MHz)	280	4.5 (50-550MHz)
S10040280GT GaAs Push Pull	40-1000	27.2 (@45MHz)/28.0 (@1000MHz)	260	5.0 (50-1000MHz)
S10040240P GaAs Push Pull	40-1000	22.5 (@50MHz)/24.0 (@1000MHz)	255	3.5 (50-1000MHz)
S10040220P GaAs Push Pull	40-1000	21.0 (@50MHz)/22.0 (@1000MHz)	270	3.5 (50-1000MHz)
S10040220GT GaAs Push Pull	40-1000	21.7 (@50MHz)/23.0 (@1000MHz)	240	6.2 (50-1000MHz)
S10040200P GaAs Push Pull	40-1000	19.5 (@50MHz)/20.0 (@1000MHz)	260	4.5 (50-1000MHz)

反向放大模块

产品名称	频率范围	最小增益	最大消耗电流	最大噪声系数
	(MHz)	(dB)	(mA)	(dB)
R2005350L Si return path low current	5-200	34.5 (@ 5MHz)/34.5 (@200MHz)	140	5.0 (5-200MHz)
R2005280L Si return path low current	5-200	27.5 (@ 5MHz)/27.3 (@200MHz)	135	3.0 (@180MHz)
R2005240P12 GaAs return path	5-200	23.5 (@ 5MHz)/23.5 (@200MHz)	360	5.0 (@10MHz)
R2005240 Si return path	5-200	23.5 (@ 5MHz)/23.3 (@200MHz)	230	3.5 (@180MHz)
R1005300L Si return path low current	5-100	30.0 (@ 5MHz)/29.8 (@100MHz)	140	3.0 (@100MHz)
R1005250L Si return path low current	5-100	24.8 (@ 5MHz)/24.6 (@100MHz)	140	3.4 (@100MHz)
R0605300L2 SMD Si return path low current	5-65	29.3 (@ 5MHz)/29.1 (@65MHz)	140	3.0 (@65MHz)
R0605300L Si return path low current	5-65	30.0 (@ 5MHz)/29.8 (@100MHz)	135	3.0 (@65MHz)
R0605280L2 SMD Si return path low current	5-65	27.3 (@ 5MHz)/27.1 (@65MHz)	140	3.0 (@65MHz)
R0605250L2 SMD Si return path low current	5-65	24.3 (@ 5MHz)/24.1 (@65MHz)	140	3.0 (@65MHz)
R0605250L Si return path low current	l5-65	24.5 (@ 5MHz)/24.3 (@65MHz)	135	3.0 (@65MHz)

光纤接收模块

产品名称	频率范围	最大消耗电流	最大噪声系数
	(MHz)	(mA)	(dB)
OS8740230W Si Optical Receiver	40-870	225	7.5 (@50MHz)/8.0 (@870MHz)
OS8740230 Si Optical Receiver	40-870	225	7.5 (@50MHz)/8.0 (@870MHz)
OS10040280GW GaAs Optical Receiver	40-1000	250	7.5 (40-750MHz)/8.0 (750-1000MHz)
OS10040280G GaAs Optical Receiver	40-1000	250	7.5 (40-750MHz)/8.0 (750-1000MHz)
OR3005230W Si Optical Receiver	5-300	190	7.5(10-300MHz)

产品命名规则：

产品封装形式：

Figure 1: Standard CATV Hybrid Package	Figure 1: Standard CATV Hybrid Package

Figure 3: CATV Hybrid Package with low profile Heatsink	Figure 4: Optical Receiver Hybrid Package with low profile Heatsink

Figure 5: SMD Package

MIXERS


Level (3)
Product	RF & LO Freq. Range	IF Freq. Range	Conversion Loss typ	Conversion Loss max	Isolation LO-RF typ	Isolation LO-RF min	Isolation LO-IF typ	Isolation LO-IF min	Input IP3 typ	LO Pwr	Pkg
	(MHz)	(MHz)	(dB)	(dB)	(dB)	(dB)	(dB)	(dB)	(dBm)	(dBm)
MXB-0502-3	2-500	DC-500	6.0	8.0	32	25	30	20	+10	+3	S07*
MXB-0503-3	2-500	DC-500	6.0	8.0	40	30	30	25	+10	+3	S07*
MXB-1002-3	500-1000	DC-1000	7.0	9.0	35	25	30	20	+11	+3	S07*
MXB-1501-3	10-1500	DC-900	7.0	9.5	25	18	18	12	+10	+3	S07*
MXB-1502-3	400-1500	DC-900	7.0	9.5	28	18	20	10	+10	+3	S07*

Level (7)
Product	RF & LO Freq. Range	IF Freq. Range	Conversion Loss typ	Conversion Loss max	Isolation LO-RF typ	Isolation LO-RF min	Isolation LO-IF typ	Isolation LO-IF min	Input IP3 typ	LO Pwr	Pkg
	(MHz)	(MHz)	(dB)	(dB)	(dB)	(dB)	(dB)	(dB)	(dBm)	(dBm)
MXB-0301-7	0.5-300	DC-200	5.5	8.0	40	25	32	20	+13	+7	S07*
MXB-0501-7	0.5-500	DC-500	6.0	8.0	28	20	25	20	+15	+7	S07*
MXB-0502-7	0.5-500	DC-500	6.0	8.0	40	30	30	25	+14	+7	S07*
MXB-1001-7	500-1000	DC-500	7.0	9.0	35	24	30	18	+13	+7	S07*
MXB-1002-7	500-1000	DC-500	7.0	8.5	30	20	26	18	+13	+7	S07*
MXB-1003-7	500-1000	DC-500	7.0	9.0	32	25	26	20	+13	+7	S07*
MXB-1501-7	10-1500	DC-1000	8.5	9.5	24	18	17	12	+13	+7	S07*
MXB-1502-7	10-1500	DC-1000	6.5	9.0	30	25	25	22	+13	+7	S07*
MXB-1901-7	5-1900	5-1000	8.5	9.5	36	20	30	20	+11	+7	S07*
MXB-2001-7	10-2000	10-1000	8.5	9.5	35	20	28	18	+10	+7	S07*
MXJ-2001-7	1-2000	10-600	7.0	9	30	25	22	20	+15	+7	S05
MXJ-2201-7	1-2200	10-600	7.5	9	30	22	22	18	+14	+7	S05
MXJ-2501-7	80-2500	DC-1000	7.5	9	25	20	20	15	+15	+7	S05

Level (10)

Product

RF & LO Freq. Range

IF Freq. Range

Conversion Loss typ

Conversion Loss max

Isolation LO-RF typ

Isolation LO-RF min

Isolation LO-IF typ

Isolation LO-IF min

Input IP3 typ

LO Pwr

Pkg

(MHz)

(dB)

(dBm)

MXB-0501-10

0.5-500

DC-500

6.0

8.0

+15

+10

S07*

MXB-0502-10

2-500

6.8

8.0

+16

+10

S07*

MXB-1001-10

5-1000

DC-1000

7.0

9.0

+15

+10

S07*

MXB-1002-10

5-1000

DC-1000

7.0

9.0

+16

+10

S07*

MXB-1501-10

10-1500

10-1000

7.0

9.5

+15

+10

S07*

MXB-1502-10

10-1500

10-1000

6.5

9.5

+15

+10

S07*

MXJ-2001-10

50-2000

10-600

7.5

+16

+10

S05

MXJ-2201-10

50-2200

10-600

7.5

+15

+10

S05

MXJ-2501-10

80-2500

DC-1000

7.5-9

+15

+10

S05


Level (13)
Product	RF & LO Freq. Range	IF Freq. Range	Conversion Loss typ	Conversion Loss max	Isolation LO-RF typ	Isolation LO-RF min	Isolation LO-IF typ	Isolation LO-IF min	Input IP3 typ	LO Pwr	Pkg
	(MHz)	(MHz)	(dB)	(dB)	(dB)	(dB)	(dB)	(dB)	(dBm)	(dBm)
MXB-0501-13	2-500	2-500	6.0	8.0	30	25	25	20	+20	+13	S07*
MXB-0502-13	2-500	2-500	6.5	8.0	40	30	32	22	+20	+13	S07*
MXB-1001-13	5-1000	DC-1000	7.0	9.0	35	25	25	18	+19	+13	S07*
MXB-1003-13	700-1000	DC-250	7.0	9.0	28	25	25	20	+20	+13	S07*
MXB-1501-13	10-1500	10-1000	6.0	9.5	25	18	20	12	+19	+13	S07*
MXB-2001-13	10-2000	10-1000	7.5	9.5	40	20	30	20	+18	+13	S07*
MXB-2501-13	10-2500	5-1500	8.0	10	30	23	25	17	+20	+13	S07*
MXJ-2001-13	50-2000	10-600	7.5	9	24	22	22	20	+20	+13	S05
MXJ-2201-13	50-2200	10-600	7.5	9	28	18	26	17	+20	+13	S05
MXJ-2501-13	80-2500	DC-1000	7.5	9	24	22	22	18	+20	+13	S05


Level (17)
Product	RF & LO Freq. Range	IF Freq. Range	Conversion Loss typ	Conversion Loss max	Isolation LO-RF typ	Isolation LO-RF min	Isolation LO-IF typ	Isolation LO-IF min	Input IP3 typ	LO Pwr	Pkg
	(MHz)	(MHz)	(dB)	(dB)	(dB)	(dB)	(dB)	(dB)	(dBm)	(dBm)
MXB-0501-17	2-500	2-500	6.0	8.0	30	25	25	20	+21	+17	S07*
MXB-0502-17	2-500	2-500	6.8	8.0	35	25	30	20	+21	+17	S07*
MXB-1002-17	5-1000	DC-1000	7.0	9.0	30	25	30	20	+21	+17	S07*
MXB-1003-17	700-1000	DC-250	7.0	8.5	32	20	40	20	+26	+17	S07*
MXB-1502-17	10-1500	10-1000	6.5	8.5	30	25	25	22	+25	+17	S07*
MXJ-0902-17	800-1000	20-100	6.2	7.0	30	25	23	20	+29	+17	S05
MXJ-2001-17	50-2000	10-600	7.5	9	23	20	20	15	+24	+17	S05
MXJ-2201-17	50-2200	10-600	7.5	9	25	20	22	14	+24	+17	S05
MXJ-2501-17	80-2500	DC-1000	7.5	9	22	20	17	12	+24	+17	S05

[ * Also available in S06 package ] [ Mixer IP3 values are typical performance ]
　

SPLITTERS

SPLITTERS
Product	Freq. Range	Isolation typ	Isolation min	Nominal Impedence	Insertion Loss typ	Insertion Loss max	Phase Unbalance max	Amplitude Unbalance max	Phase Offset	Pkg
	(MHz)	(dB)	(dB)	(ohms)	(dB)	(dB)	(deg)	(dB)
SPA-0101-27	5-65	31	28	75	0.2	0.35	±3.0	0.3	0º	S06
SPA-0301-27	1-250	24	20	75	0.8	1.0	±1.5	0.6	0º	S06
SPA-0501-25	1-500	35	20	50	0.4	1.0	±4.0	0.3	0º	S06
SPA-0701-25	1-650	35	18	50	0.4	1.0	±3.0	0.3	0º	S06
SPA-1001-25	800-980	23	20	50	0.5	1.0	±2.0	0.5	0º	S06
SPA-1001-27	50-1000	22	18	75	0.8	1.0	±3.0	0.4	0º	S06
SPA-1002-27	5-1000	22	18	75	0.9	1.2	±9.0	0.4	0º	S06
SPA-2501-25	1700-2500	20	16	50	0.8	1.4	±3.0	0.5	0º	S06
SPE-1001-25	810-960	25	18	50	0.6	1.0	±3.0	0.3	0º	S08
SPC-1001-25	800-1000	20	12	50	0.3	1.0	±3.0	0.4	0º	S10
SPC-1601-25	1200-1600	18	10	50	0.4	1.0	±5.0	0.5	0º	S10
SPC-2001-25	1600-2000	18	15	50	0.4	0.8	±3.0	0.5	0º	S10
SPC-2201-25	1800-2200	25	18	50	0.4	0.8	±3.0	0.5	0º	S10
SPC-2601-25	2000-2600	18	10	50	0.5	1.2	±8.0	0.8	0º	S10

TRANSFORMERS


Balanced to Balanced
Product	Frequency Range	Impedance Ratio	3dB	Insertion Loss Bandwidth 2dB	1dB	Pkg
	(MHz)		(MHz)	(MHz)	(MHz)	(dB)
XFA-0101-1B	.008-80	1:1	.008-80	.008-80	.015-40	S06
XFA-0201-15B	.075-200	1:1.5	.075-200	1-125	.3-65	S06
XFA-0101-25B	.009-50	1:2.5	.009-50	.015-25	.034-10	S06
XFA-0201-3B	.08-155	1:3	.08-155	.11-110	.27-40	S06
XFA-0301-4B	.1-240	1:4	.1-240	.2-210	.3-180	S06


Unbalanced to Balanced
Product	Frequency Range	Impedance Ratio	3dB	Insertion Loss Bandwidth 2dB	1dB	Pkg
	(MHz)		(MHz)	(MHz)	(MHz)	(dB)
XFK-0401-2W	3-400	1:2	-	3-400	3-400	S01
XFK-0301-4W	1.5-300	1:4	-	1.5-300	10-300	S01
XFK-0401-4W	20-400	1:4	-	20-400	-	S01
XFK-0901-4W	8-900	1:4	-	8-900	-	S01
XFM-0401-4W	1-350	1:4	1-350	2-300	5-100	S03
XFM-1002-4W	1-1000	1:4	1-1000	-	-	S03
XFA-0201-1W	.006-150	1:1	.006-150	.008-120	.016-50	S06
XFA-0301-1W	.05-300	1:1	.05-300	.08-200	.15-100	S06
XFA-0301-2W	.05-280	1:2	.05-280	.08-180	.16-100	S06
XFA-0301-3W	.06-300	1:3	.06-300	.1-275	.23-230	S06
XFA-0301-4W	.03-300	1:4	.03-300	.04-250	.15-175	S06
XFA-0401-4W	.2-350	1:4	.2-350	.35-300	2-170	S06
XFA-0201-8W	.05-125	1:8	.05-125	.08-100	.24-75	S06
XFA-0101-16W	.03-75	1:16	.03-75	.05-45	.18-25	S06


Unbalanced to Unbalanced
Product	Frequency Range	Impedance Ratio	3dB	Insertion Loss Bandwidth 2dB	1dB	Pkg
	(MHz)		(MHz)	(MHz)	(MHz)	(dB)
XFA-0401-1U	1-400	1:1	1-400	5-200	-	S06
XFA-0101-25U	.011-180	1:2.5	.011-180	.0175-160	.05-125	S06
XFA-0301-4U	.05-220	1:4	.05-220	.07-180	.18-150	S06
XFA-0101-16U	.165-75	1:16	.165-75	.36-50	1.6-20	S06

COUPLERS

Couplers
Product	Freq. Range	Nominal Impedence	Coupling	Mainline Loss midband typ	Mainline Loss midband max	Directivity midband typ	Directivity midband min	VSWR typ	RF Power max	Pkg
	(MHz)	(ohms)	(dB)	(dB)	(dB)	(dB)	(dB)	(:1)	(dBm)
CPK-1001-716	5-1000	75	16±0.5	0.7	1.2	30	16	1.3	+33	S01
CPA-0501-510	5-500	50	10±0.5	0.8	1.1	30	22	1.3	+33	S06
CPA-1001-716	1-1000	75	16±0.7	1.0	2.0	30	20	1.22	+33	S06

ISOLATORS

Model Number

Freg. Range

Unit Type

Iso min

Insert Loss Max

VSWR max

Temp C°

Input Power
Peak	Avg.

Reflected Power
Peak	Avg.

Package Size

(MHz)

(dB)

(Inch)

PI0860DG-21

850-870

Drop in

0.35

1.22

-30 to +85

1 "

PI0943DG-21

925-960

Drop in

0.35

1.22

-30 to +85

1 "

PI1843DG-21

1805-1880

Drop in

0.35

1.22

-30 to +85

1 "

PI1960DG-21

1930-1990

Drop in

0.35

1.22

-30 to +85

1 "

ISO-ATTENUATORS

Model Number

Freg. Range

Unit Type

Iso min

Insert Loss Max

VSWR max

Temp C°

Input Power
Peak	Avg.

Reflected Power
Peak	Avg.

Package Size

(MHz)

(dB)

(Inch)

PA0853DG-41

825-880

Drop in

0.35

1.22

-30 to +85

1 "

PA0903DG-41

885-920

Drop in

0.35

1.22

-30 to +85

1 "

PA0903DG-42

925-960

Drop in

0.35

1.22

-30 to +85

1 "

PA0943DG-41

925-960

Drop in

0.35

1.22

-30 to +85

1 "

PA0943DG-42

925-960

Drop in

0.35

1.22

-30 to +85

1 "

CIRCULATORS

Circulators
Model Number	Freg. Range	Unit Type	Iso min	Insert Loss Max	VSWR max	Temp C°	Input Power		Reflected Power		Package Size
Model Number	Freg. Range	Unit Type	Iso min	Insert Loss Max	VSWR max	Temp C°	Peak	Avg.	Peak	Avg.	Package Size
	(MHz)		(dB)	(dB)							(Inch)
PC0882DG-21	869-894	Drop in	20	0.30	1.22	-40 to +85	100	100	100	100	1 "
PC0943DG-21	925-960	Drop in	20	0.30	1.22	-40 to +85	100	100	100	100	1 "
PC1843DG-21	1805-1880	Drop in	20	0.30	1.22	-40 to +85	100	100	100	100	1 "
PC1843DE-21	1805-1880	Drop in	20	0.30	1.22	-40 to +85	100	100	100	100	0.75 "
PC1960DG-21	1930-1990	Drop in	20	0.30	1.22	-40 to +85	100	100	100	100	1 "
PC1960DE-21	1930-1990	Drop in	20	0.30	1.22	-40 to +85	100	100	100	100	0.75 "
PC1908DE-21	1895-1920	Drop in	20	0.30	1.22	-40 to +85	100	100	100	100	0.75 "
PC2018DE-41	2010-2025	Drop in	20	0.30	1.22	-40 to +85	100	100	100	100	0.75 "
PC2150DG-21	2100-2200	Drop in	20	0.30	1.22	-40 to +85	100	100	100	100	1 "

Power Amplifier

Product	RF Freq. Range	min Power Gain	P1dB	ACPR (+/- 600kHz)	ACPR (+/- 900kHz)	Input VSWR
	(MHz)	(dB)	(dBm)	(dBc)	(dBc)
P1935	1880-1920	35	35	-64	-71	1.5

Low Noise Amplifier

Product	RF Freq. Range	Power Gain	Noise Figue	min IIP3	min S11	min S22
	(MHz)	(dB)	(dB)	(dBm)	(dB)	(dB)
L1935	1800-1950	35	0.9	10	20	20

PACKAGES

Packages
S01 5 pin Surface Mount	S03 5 pin Surface Mount	S05 5 pin Surface Mount
S06 6 pin Surface Mount	S07 6 pin Surface Mount	S10 10 pin Surface Mount
S14 6 pin Surface Mount	T15 6 pin Thru Hole	S16 6 pin Surface Mount

供应商信息

公司：商斯达(香港深圳北京上海西安)有限公司
联系人：销售部(香港深圳北京上海西安成都武汉等设分公司特价连锁经营）
电话：0755-83376489 83778810 83600718
手机：13823676822微信同号
传真：0755-83376182
Email：xjr5@163.com
QQ：583757894 1295084882
地址：深圳市福田福华路鸿图大厦1602室、2005-2006室;:上海市北京东路668号上海賽格电子市场 : 西安高新开发区20所(导航技术研究所)

电子百科

产品导航

PHILIPS RF 器件

商品详情

供应商信息

最新产品

IC37:专业IC行业平台
